Used Well Drilling Rig

300m FY300 Used water well drilling rig borehole machine

300m FY300 Used water well drilling rig borehole machine

Condition: Used
Drill Depth: 300m
Model: FY300
Manufacture date: 2020
If you are interesting at 300m FY300 Used water well drilling rig borehole machine,you can contact us with the inquiry button.
INQUIRY WhatsApp

Description of 300m FY300 Used water well drilling rig borehole machine

FY300 300m Used water well Drilling Rig for sale.

Machine is in good condition, 2020 production date, all issues have been overhauled.

300 meters water well drilling rig features

1. It is an efficient and multifunctional groundwater drilling equipment, that can be used for drilling water wells, agricultural irrigation wells, geothermal wells, and other wells. It is especially suitable for water intake projects in mountainous areas and rock formations.

2. The machine can drill holes in different formations (rock, mud, sand layers), and the maximum hole diameter can reach 300mm.

3. This machine adopts a high-torque hydraulic motor power head and brand diesel oil, and the hydraulic control system adopts a large-diameter hydraulic cylinder. A two-stage air filtration system protects the brand diesel, and the clean air from the air compressor can also be used directly.

4. Unique bump design and centralized control operating system are easy to maintain and operate.

5. This machine adopts an excavator crawler chassis, which has high off-road performance and can also be installed on trucks, with stronger mobility.

6. Two gear rotation and feed speed to make it work in soil and rock layers.

7. Easy to operate, one man can manage it with the operating panel.

8. Dual systems can be installed: 1. Air power system with air compressor 2. Mud Pump system with mud pump

PD300 crawler water well drilling rig specifications
The weight（T）	7.2	Drill pipe diameter（mm）	Φ76 Φ89 Φ102
The hole diameter（mm）	140-325	Drill pipe length（m）	1.5m 2.0m 3.0m
Drilling depth（m）	300	Rig lifting force（T）	18
One-time advance length（m）	3.3/4.8	Rapid rise speed（m/min）	22
Walking speed（km/h）	2.5	Fast feeding speed（m/min）	40
Climbing angles（Max.）	30	Brand	Pearldrill
Equipped capacitor（KW）	85	Hoisting force of winch（T）	2
Using air pressure（MPA）	1.7-3.0	Swing torque（N.m）	5700-7500
Air consumption（m³/min）	17-36	Dimension（mm）	4100×2000×2500
Swing speed（rpm）	40-70	Equipped with hammer	Medium and high wind pressure series
The penetration efficiency（m/h）	15-35	High leg stroke（m）	1.4
The engine brand	Yuchai engine
