  • Small Portable mobile Water Well Drilling Rigs
  • Small Portable mobile Water Well Drilling Rigs
  • Small Portable mobile Water Well Drilling Rigs
  • Small Portable mobile Water Well Drilling Rigs
  • Small Portable mobile Water Well Drilling Rigs
Small Portable mobile Water Well Drilling RigsSmall Portable mobile Water Well Drilling RigsSmall Portable mobile Water Well Drilling RigsSmall Portable mobile Water Well Drilling RigsSmall Portable mobile Water Well Drilling Rigs

Small Portable mobile Water Well Drilling Rigs

  • Drill Hole Depth:100-150m
  • Power Type:Gasoline/Disel
  • Weight:200 Kg
  • Drilling Depth:120m
  • 在线订购

water well <a href=https://www.gzpearldrill.com/en/Drilling-Rig.html target='_blank'>Drilling Rig</a>s for sale

This small movalble disel water well drilling rig machine is mainly used for geothermal drilling, farm irrigation, house yard, gardens, and water well drilling, drilling diameter is 70-350mm, and the drilling depth is 80m to 100m. The water well drilling rig machine also can be used in small building piling, like farmhouses or factories, the drilling diameter can reach 500mm and the depth can be more than 200 meters.


Technical Parameter


Rig model

ZSJD-100 type

Motor Power

4000W

Drill pipe diameter

42mm

Drilling and crushing method

Impact Rotary

Dimensions

80cm*80cm*245cm

Drilling depth

100-200M

Drill pipe length

1.5m

Pump power

2.2KW

Rig weight

200KG

Drilling diameter

Within 400mm

Drill pipe replacement method

Thread button (automatic double thread)

Machine Height

2 meters

Applicable voltage

220V/380V

Force

1000KG

Rig model

ZTJD-150 type

Motor Power

4000W

Drill pipe diameter

50mm

Drilling and crushing method

Impact Rotary

Dimensions

90cm*90cm*245cm

Drilling depth

100-200M

Drill pipe length

1.5m

Pump power

2.2KW

Rig weight

250KG

Drilling diameter

Within 400mm

Drill pipe replacement method

Thread button (automatic double thread)

Machine Height

2 meters

Applicable voltage

220V/380V/
Gasoline / Diesel

Force

2000KG

Rig model

ZTJD-180 type

Motor Power

4000W

Drill pipe diameter

50mm

Drilling and crushing method

Impact Rotary

Dimensions

100cm*100cm*245cm

Drilling depth

100-200M

Drill pipe length

1.5m

Pump power

2.2KW

Rig weight

290KG

Drilling diameter

Within 500mm

Drill pipe replacement method

Thread button (automatic double thread)

Machine Height

2 meters

Applicable voltage

220V/380V/
Gasoline / Diesel

Force

2000KG


Product Details

water drilling rig

small water well drill rig

disel movable water well <a href=https://www.gzpearldrill.com/en/Drilling-Rig.html target='_blank'>Drilling Rigs</a>



china water well drill rig

Product Features

1、This small drilling machine occupies a small area (1 square meter), and a height of 2 meters stand, the job can be installed in less than ten minutes. can be used at indoor and outdoor sites.

2、The good pipe is fully enclosed, and the shallow layer has no leakage, which can ensure the health and safety of drinking water.

3、Research and Develop by ourselves, it breaks difficult problems that are easy to drill and hard to disassemble.

4、All the lifting, loading, and unloading of drill pipe is mechanized, time-saving, labor-saving, and easy to operate.


water well drilling rig for sale

Product Advantages

1 Light weight, energy saving.
2、Patented product, unique design, and simple drilling structure;
3、Easy to transport and can learn how to handle the machine in a short time;
4、Can drill through hard stratum, unless thick rock layer ;
5、
One-person operation, reduce the labor intensity ;
6、High efficiency and work fast.

7、Assure easy operation and long life service life, free maintenance.
