Small Portable Diesel Crawler DTH Diamond Bit Drilling Rig For Water Well Drill

Basic Info.

Model NO.
FYX180
Condition
New
Motor
AC Motor
Drill Hole Diameter
250-300mm
Drill Hole Depth
150-200m
Bit Type
Diamond Bit
Drilling Way
Rotary
Type
Crawler
Using Air Pressure
1.7-2.5MPa
Diesel Engine
Quanchai Brand
One Time Advance Length
3.3m
Walking Speed
2.5km/H
Drill Pipe Diameter
76, 89mm
Climbing Angle
30 Degree
Fast Feeding Speed
40m/Min
Rapid Rise Speed
20m/Min
Air Consumption
17-31m3/Min
Swing Torque
3200-4600n.M
Drilling Speed
10-35 M/H
Swing Speed
45-70rpm
Drill Pipe Length
1.5, 2.0, 3.0m
Host Power
55kw
Total Weight
4.5t
Transport Package
Export Standard Seaworthy Packing
Specification
3950x1600x2250mm
Trademark
Duobo
Origin
Shandong, China
HS Code
843041
Production Capacity
1000 Sets/Year


FYX series rotary full hydraulic control water well drilling rig is multifunctional, it can be used with an air compressor, and mud pump, even we can only use the dry hydraulic drilling method.
Portable drilling rigs are not only designed for water, they can also be used in all conditions depending on the hole forming purpose.
This series of water well drilling rigs has the characteristics of standardized configuration, compact and reasonable structure, fast drilling speed, economical and durability, and low failure rate. Once launched, it has been recognized by the market and has been widely used in mining engineering construction, civil drilling, geothermal drilling, and other fields.
Widely used in industrial and agricultural water conservancy projects, test wells, and another exploration drilling. In particular, geothermal heating drilling can also meet various projects of engineering foundation reinforcement, loose gravel drilling, and rock formation connection.
Our drilling rigs are more efficient, have lower failure rates, are more economical and durable, and have comprehensive cost-effectiveness.
